Outstation Override Master Station Override Parent Point Override Note

Priority of Point Background Colors

This chart indicates which point status takes precedence over another, and therefore which core system background color is assigned to a point at any particular time (unless a driver-specific state and associated color takes precedence):

Further Information

List of Core System Colors.
